MAYA 9B

The minimalist design of the Maya 9B projectors finds a place in low height installations, whether wall or ceiling. The small height footprint is designed to offer little exposure to wind. It provides high efficiency and uniformity of illuminance with a choice of more than 40 optics, both symmetrical and asymmetrical.
Up to lm/w (D)
Up to lm/w (P)
Energy Class A++, CE, RoHS, EN 60598-2-22, ENEC pending

Control systems

DM, 1-10V, DALI, D4i

Increased inclination

Tilt angle: -90°/ 90°

Speed of installation

Increased inclination

Tilt angle: -90°/ 90°

Speed of installation

- Suitable for powers up to 154 W.

- Supercast(R) die-cast aluminum body for better dissipation and corrosion resistance due to very low copper content.

- PHILIPS/TRIDO NIC drivers integrated within the product.

- Full cut-off optics.

- Tempered glass to protect optics and LEDs.

- System efficiency of up to 176lm/W

- Ideal for use as an under-gutter street light or for illuminating outdoor areas of industrial warehouses, parking lots.

- Complies with all Regional Laws for the reduction of light pollution.

- Modern design for installations a few meters above the ground.

No items found.
ModelLED module fluxIlluminating body flowNo. of LEDsCurrent (mA)P[W]lm/w illuminating body
ModelLED module fluxFlowNo. of LEDsCurrent (mA)P[W]lm/w tot
